Electrically Actuated Flanged V-Port Ball Valve (LQ Series)

Electrically Actuated V-Port Ball Valve with LQ Series actuator operates without external servo amplifier. Input signals (4-20mA DC/0-10V DC/1-5V DC) and single-phase power enable precise regulation of pressure/flow/temperature/liquid level parameters. The V-notch on the ball core generates shearing force through rotation against the hard-sealed seat, effectively cutting fibers to prevent jamming. Featuring high flow capacity, accurate regulation, and premium sealing performance with lightweight construction, this valve suits most applications except small-bore/angle/tri-clamp connections. Particularly effective for slurry/fibrous media and suspensions with micro solids, it serves as optimal replacement for imported valves in papermaking/sugar refining/petrochemical/metallurgical automation systems.
