SAFE, Surpassing Quality!
Adhering to IEC 60534 Class V Leakage Rate
As Our Factory Standard
Seat & Body Sealing
• Embedded body seal
• Ensures internal/external sealing integrity
• Unique seat profile design
• Guarantees upstream/downstream sealing effectiveness
• Elastic seat absorbs compressive stress
• Self-adjusting seat support optimizes operating torque
• Seat collar design
• Prevents axial displacement when upstream pressure exceeds downstream
Standard Specifications
• Actuation: Electric actuator
• Nominal Diameter: DN15-DN100
• Pressure Rating: 1.6MPa/Custom higher pressures
• Temperature Range: Domestic PTFE -10~100℃/Imported PTFE -10~150℃
• Media Compatibility: Gas/Water/Oil
• Optional Accessories: C220V, 380V, DC24, On-Off type, Switch-regulating type
• Connections: Welded/Quick-connect/Flanged
• Body Material: Cast steel/CF8 (304)/CF3 (304L)/CF8M (316)/CF3M (316L)
Technical Parameters
• Flange Standards: GB/JB/HG/API/ANSI/DIN/JIS/JPI/BS
• Body Material: CF8 (304)/CF3 (304L)/CF8M (316)/CF3M (316L)
• Working Pressure: 1.0MPa-2.5MPa
• Working Temperature: -15℃-180℃
• Connections: Internal thread/External thread/Industrial flange/Sanitary flange/Butt weld/Socket weld/Quick-connect/Compression fitting
• Actuation: Pneumatic actuators/Electric actuators/Hydraulic actuators
• Nominal Diameter: DN8-DN100 ∮12.7-∮101.6
